ASCE 7 Components & Cladding Wall Wind Pressure Calculator

Important Message from Engineering Express

By clicking below, you agree that the use of this design aid is for estimating purposes only. Results are not valid for use & no construction or design shall be performed without the review and certification by a registered professional engineer.

No warranty or guarantee whatsoever is offered with any results obtained herein.


AGREE & CONTINUE

Use this tool to calculate positive & negative ASD design wind pressures for ASCE wall zones 4 & 5.

Watch The Tutorial

1. This calculator is for estimating purposes only & NOT for permit or construction. Results are ONLY valid when signed & sealed from a professional engineer from Engineering Express

If you would like signed & sealed results, please make sure you are logged into your Engineeringexpress.com account prior to inputting your data in both input areas 1 and 2. Press ‘Order Certified Copies For Permit’ which appears after all fields are filled out to order a review of your submission & PE certification once approved, it will be delivered to you for permit submission.

2. Do not use fractions. Round up everything but width and height – round those down.

3. Pressure results are the Allowable Stress Design (ASD) method.

4. Suggested Wind Velocity & Exposure category requirements can be found by confirming with the permit building department before using or visit the ASCE Hazard Tool.

* For residential structures (Risk Category II’) in Broward & Palm Beach Counties, the required wind velocity is 170mph.

* For residential structures (‘Risk Category II’) in Miami-Dade County, the required wind velocity is 175mph.

* If you are near the coast, it’s Exposure Category ‘D”; Inland is Exposure Category ‘C’.

5. Visit our Wind Page to learn more about the terms & parameters of this tool & HOVER over / press on the input labels for more information about that item.

6. Discounts are available for frequent users by purchasing Tokens

Click for a glossary of terms

Calculator last updated Feb 8, 2022
ASCE 7-22 C&C Calculator - V2.13 - 7 09 2024
ASCE COMPONENTS & CLADDING WALL OPENING
WIND LOAD CALCULATOR
SEE HELP & IMAGE AT BOTTOM - HOVER/CLICK LABELS FOR HELP

Click to read our informative help page on this tool.

INPUT AREA 1 SITE CONDITIONS UNITS
Consult your building department or engineer for governing codes and design standards ASCE CODE YEAR

Ultimate Wind Speed, Vult, based on location
This can be found at hazards.atcouncil.org and is subject to your local building departmet       WIND VELOCITY, Vult
MPH
Determine your site exposure category. Help can be found at ecalc.io/Exposure      ASCE EXPOSURE CATEGORY

This is generally 0.85. Change to 1.0 only if required by building department or special use case directed by the architect / engineer. WIND DIRECTIONALITY FACTOR Kd

Wind pressures are calculated for flat terrain by default. Local hills or ridges may increase calculated wind pressures. LOCAL TOPOGRAPHY

Use 1.0 for flat terrain. For areas on or near hills, ridges, or escarpments, this factor helps account for wind speeding up as it flows over the land. If required, this factor can be calculated separately by Engineering Express or the design engineer. Refer to the help glossary above for more information. TOPOGRAPHY FACTOR Kzt

For every 1,000 above sea level, atmospheric pressure and corresponding wind pressure is decreased per ASCE 7‐16. Select 0 if unsure or at sea level. ELEVATION ABOVE SEA LEVEL
FT
See help and image below. This is the shortest building dimension. The width of End zone 5 is 10% of this value, 40% of height, or not less than 3’ MIN OVERALL BLDG DIMENSION
FT
This is the average roof height from the peak to the eave. See image below. Your minimum heights will be adjusted to these values:
Exposure B => 30'
Exposure C => 15'
Exposure D => 7' MEAN ROOF HEIGHT, MRH
FT
For buildings over 60 FT, a reduction is permitted for positive pressures based on the actual elevation. Enter the elevation from ground to the lowest opening being analyzed. LOWEST INSTALLATION ELEVATION
FT
If the roof slope is less than 10 degrees, there is a slight reduction in pressure. If complex roof or unsure, set to >= 10°.

 ROOF SLOPE

# OF OPENINGS TO ANALYZE
If yes, the calculaon for area of opening switches from Width * Height to Height * Height/3. It operates on the assumpon that impact shuers are tested infinite width. IMPACT SHUTTER ANALYSIS



INPUT AREA 2
Positive values represent pressures directed at or against the building. Negative values are pressures pushing outward from inside the building, or creating suction on exterior faces. Expect larger negative values due to building pressurization. CALCULATED PRESSURES
AT EACH OPENING OR COMPONENT
ZONE 5 CORNER DIST 'a' =
This is your label to help identify the answer on accompanying layout drawings. MARK
(W*L)/144 must be lower than 700ft² to use the C&C method. WIDTH-in
(W*L)/144 must be lower than 700ft² to use the C&C method. HEIGHT-in
Area considered shall be the smaller of W*H or H * H/3
(And shall always be H*H/3 for analysis of Impact Shutters) AREA-ft2
Use zone 5 for openings near building corners (anything within the "a" distance listed above). Use Zone 4 for openings along the midspan of the wall. Refer images below.
If Zone is unclear, use Zone 5 ZONE
POSITIVE NEGATIVE

EXAMPLE ILLUSTRATIONS:   Fill out all fields to order certified copies















Version 2.6
© Engineering Express
Updated 7/09/2024
Wind pressure calculator
Wind pressure calculator

ASCE 7 Components & Cladding Wall Wind Pressure Calculator

$150.00 or ( 15 Tokens )

Calculate components & cladding wall pressures for up to 50 openings. Easily order certified copies for review & permit.

Read More
Please select the state you would like the document certified in
Please choose whether this is for a multi-story building or not
This field can't be Empty
This field can't be Empty
Please choose the permitting party
This field can't be Empty
Please provide consent for your data accuracy.
When choosing Sealed Hardcopy, maximum quantity is 1.
3 copies are sent per order.
Save up to an additional 33% by using tokens Learn more

As of November 1, 2024, All building departments in Broward county require files submitted to their online permitting portal to be formatted differently. Delray Beach requires the same type of formatting for our TERs instead of selecting individually seal each page.

Need the drawing earlier than 24 hours? We now have the option to expedite it for a fee! Please note expedited orders only applies to digitally signed and sealed documents during our business hours. Any orders placed over the weekend and or after business hours with the expedition fee will be applied to the next business day.

View Sample

Weight 1 lbs
Dimensions 9 × 12 × 0.1 in
Plan Format

Digitally Sealed Online-Only File, Raised Sealed Embossed Physical Copy
The document you are purchasing is a generic performance evaluation. Use of this document for any site-specific application is the responsibility of others. Installations beyond the performance limitations listed within the purchased document, any site-specific designs/certifications, or California-specific projects shall require custom engineering and invalidate the use of this evaluation. Learn more about the use of this document

Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
