Trane: Tie-downs to A/C Stand, Wall Bracket, or Concrete
Trane: Tie-downs to A/C Stand, Wall Bracket, or Concrete

Trane: Tie-downs to A/C Stand, Wall Bracket, or Concrete

$60.00 – $80.00 or ( 6 Tokens - 8 Tokens )

This document is sold as an engineer-certified report for Trane: Tie-downs to A/C Stand, Wall Bracket, or Concrete Performance Evaluation Report and is available as a sealed drawing. The document meets the requirements for structural wind integrity per the selected building code above, using ASCE 7 for the tie-down clip capacities. This report will be signed and sealed by a Professional Engineer of the firm when purchased and delivered to you via email (using the digital seal method, within 24 hours) or mail (UPS Ground for printed and signed hardcopies, next day in South Florida). Use it with your site-specific documents to obtain a building permit.

Digitally certified documents are licensed to the provided contractor and zip code up to the time frame listed. For extensions beyond that date, you can use the Online Chat to request an extension.

Installation variations and site-specific drawings outside the scope of this plan can be quoted using our online smart request form by clicking here.

This product can be used with the following:

Model Number Unit Dimensions (in)
Width  Depth Height
5HPL5024A1 38.77 16.50 31.66
5HPL5036A1 42.62 19.44 33.77
5HPL5048A1 39.96 14.37 52.36
5HPL5060A1 39.96 14.37 52.36
A5HL5024A1 38.77 16.50 31.66
A5HL5036A1 42.62 19.44 33.77
A5HL5048A1 39.96 14.37 52.36
A5HL5060A1 39.96 14.37 52.36
E4HL5018A1000A* 35.59 13.69 31.61
E4HL5024A1000A* 35.59 13.69 31.61
E4HL5030A1000A* 35.59 13.69 31.61
E4HL5036A1000A* 35.59 13.69 31.61
E4HL5042A1000A* 37.16 13.31 52.72
E4HL5048A1000A* 37.16 13.31 52.72
E4HL5060A1000A* 37.16 13.31 52.72
M5THS1909A11NAA* 28.66 12.01 21.65
M5THS1912A11NAA* 28.66 12.01 21.65
M5THS1918A11NAA* 33.27 14.96 27.52
M5THS1924A11NAA* 35.83 16.54 31.50
M5THS1936A11NAA* 35.83 16.54 31.50
M5THS2309A11NAA* 28.66 12.01 21.65
M5THS2312A11NAA* 28.66 12.01 21.65
M5THS2318A11NAA* 33.27 14.96 27.52
M5THS2324A11NAA* 35.83 16.54 31.50
Read More
Please select the state you would like the document certified in
Please choose whether this is for a multi-story building or not
This field can't be Empty
This field can't be Empty
Please choose the permitting party
This field can't be Empty
Save up to an additional 33% by using tokens Learn more

As of November 1, 2024, All building departments in Broward county require files submitted to their online permitting portal to be formatted differently. Delray Beach requires the same type of formatting for our TERs instead of selecting individually seal each page.

Need the drawing earlier than 24 hours? We now have the option to expedite it for a fee! Please note expedited orders only applies to digitally signed and sealed documents during our business hours. Any orders placed over the weekend and or after business hours with the expedition fee will be applied to the next business day.

View Sample

Product Documents

Sample Documents

Product Documents

Sample Documents

Weight 0.32 lbs
Dimensions 0.0100 × 17.0000 × 11.0000 in
Plan Type

Clip / Tie-Down, Master Plan Sheet – MPS
Storefront

trane, Engineering Express
Plan Format

Digitally Sealed Online-Only File, Raised Sealed Embossed Physical Copy
The document you are purchasing is a generic performance evaluation. Use of this document for any site-specific application is the responsibility of others. Installations beyond the performance limitations listed within the purchased document, any site-specific designs/certifications, or California-specific projects shall require custom engineering and invalidate the use of this evaluation. Learn more about the use of this document

Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
