2” BERTHA™ Polycarbonate Clear Panel Support Page

This design aid is the digital counterpart for the Statewide Product Approval FL28390

& contains helpful content to make Eastern Bertha Clear Panels easier to understand, use & install



This is the digital counterpart to FL Product Approval FL28390



These storm panels not only provide maximum visibility and light but also strength and durability.

You can choose to have just one or a few of our Polycarbonate Clear Panels intermixed with our Aluminum Panels, or you can use these panels for the entirety of your project.

clear berthapanel
Visit FL28390 on the Florida Approval Website
See connection details and other calculator Info
Shutter Calculatorv7
Design Aid For:
Eastern Metal Supply 2" Clear Bertha Storm Panel
FL Product Approval v7                               04/04/2019
Order Certified Copies of these preliminary results - useful for permitting
FIRST ENTER SHUTTER SPAN AND REQUIRED DESIGN PRESSURE
HIGH VELOCITY HURRICANE ZONE?
SHUTTER SPAN in (SEE FIGURE FOR EXPLANATION)
REQUIRED NEGATIVE  DESIGN PRESSURE psf
Click  Here to Continue & Agree to Terms

PLEASE SELECT:
REQUIRED SEPARATION FROM GLASS (SEE FIGURE FOR EXPLANATION)
SEE BELOW FOR ANCHORAGE OPTIONS
HOST SUBSTRATE
CONNECTION TYPE
(SEE FIGURE BELOW FOR EXPLANATION)
DESIRED ANCHOR
REQUIRED ANCHOR SPACING

    Aside from a complete approval report counterpart of the same FL number, this approval uses a digitally available component useful for further information about the product specifications, limitations, and availability.
The web page counterpart also contains a design aid that performs interpolation of span, pressure, and anchor data for higher resolution results. As that information resides outside this evaluation, any results obtained from the web page shall be reviewed and certified by an engineer from this firm.
More instructions can be found by visiting that web site. This approval shall only be valid if that information is available online.
